2 Ton Mezzanine Industrial Hydraulic Lift Multi Level Warehouse Goods Handling

Brand Name:	HAOXIANG BRAND
Model Number:	DSL2-3
MOQ:	1 unit
Price:	USD1600- USD6800 / UNIT
Payment Terms:	T/T
Supply Ability:	2000 units per year

Detail Information

Product Description

Detail Information

Place of Origin:

GUANGDONG,CHINA

Certification:

CS/ISO

Door Opening Size:

Customized

Platform Size:

2.5m*2.5m

Capacity:

2000kg

Control System:

PLC Control

Lifting Height:

Material:

Steel

Product Name:

Hydraulic Guide Rail Lift

Country Of Origin:

Made In China

Control Mode:

Hydraulic

Rated Load:

Up To 30 Tons,Customizable

Packaging Details:

Naked packaging

Highlight:

2 Ton Industrial Hydraulic Lift

Cargo Handling Industrial Hydraulic Lift

2 Ton mezzanine goods lift

Product Description

2 Ton Hydraulic Guide Rail Lift with Safety Interlocks, 3m Travel Height, for Multi-Level Warehouse Cargo Handling

Durability is at the core of the Hydraulic Guide Rail Lift. It is coated with industrial-grade powder paint to resist corrosion and environmental damage. The platform uses thickened checker plate steel that provides anti-slip performance and strong load-bearing capacity. With its robust design, the lift requires minimal maintenance and offers long-term performance under heavy-duty conditions.

Technical Parameter
Specifications, sizes and colors can be customized according to customer requirements
Model	Rated load (kg)	Lifting stroke (mm)	Lowering height (mm)	Table size (mm)	Lifting time	Motor power (kw)
DSL1-3	1000	3000	100	2000×1800	6m/min	3
DSL1-12	1000	12000	100	2500×2000	6m/min	3
DSL2-4	2000	4000	150	2000×1800	6m/min	4
DSL2-10	2000	10000	200	3000×3500	6m/min	4
DSL3-5	3000	5000	150	3000×1800	6m/min	5.5
DSL3-8	3000	8000	150	2000×1700	6m/min	5.5
DSL4-5	4000	5000	250	3000×4000	6m/min	7.5
DSL4-10	4000	10000	150	5000×3000	6m/min	7.5
DSL5-6	5000	6000	400	5800×3000	6m/min	11
DSL10-15	10000	15000	400	7000×5000	6m/min	18.5
DSL15-9	15000	9000	800	8000×4000	6m/min	30
DSL15-10	15000	10000	800	9000×4500	6m/min	30
