Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler

Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler

Brand Name: HAOXIANG BRAND
Model Number: HX-GTY 6×5
MOQ: 1 unit
Price: USD 1500-2000 /UNIT
Payment Terms: T/T
Supply Ability: 5000 UNITS PER YEAR
Detail Information
Product Description
Detail Information
Place of Origin:
GUANGDONG,CHINA
Certification:
CE/ISO
Voltage:
220V/380V/415V
Load:
6000-10000kg
Device Size:
W1980 × L1830× H495mm
Color:
Blue,Green,Customers' Requirements
Adjustment Range:
+400mm/-300mm
Size:
Customized Size
Packaging Details:
Naked packaging
Highlight:

Fixed scissor lifting platform for warehouse

,

Space-saving high-height dock leveler

,

Edge-mounted fixed dock leveler

Product Description
Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler
Hydraulic dock levelers stand as a vital connection for smooth, secure cargo transfer, utilizing sophisticated hydraulic systems: a primary hydraulic cylinder lifts the platform, while a secondary cylinder precisely adjusts the lip plate to create a tight, gap-free fit with truck beds. This fixed design flexibly accommodates diverse vehicle height demands and logistics scenarios, eliminating inefficiencies of traditional load-handling approaches and integrating seamlessly with most trucks and shipping containers.
Key Benefits
  • Ergonomic Electro-Hydraulic Control: The intuitive electro-hydraulic operation system streamlines operational workflows, boosting loading and unloading efficiency by reducing manual labor and significantly cutting down operational costs.
  • High-Strength Distortion-Resistant Steel Frame: Crafted from manganese steel square tubing, the frame offers exceptional load-bearing capacity and structural stability, resisting deformation even under continuous heavy-duty use.
  • Enhanced Maintenance Safety Support: A sturdy safety support safeguards maintenance personnel during internal inspections or servicing, minimizing on-site accident risks and potential hazards.
  • Leak-Proof Hydraulic Module: The sealed, integrated hydraulic unit is equipped with high-precision connectors to prevent oil leakage, ensuring reliable long-term performance in harsh working environments.
Technical Specifications
Specifications, sizes and colors can be customized according to customer requirements
Model Equipment specifications (mm) Load Capacity (t) Pit size (mm) Adjustment range (mm)
HX-GTY6×6 1830(W)×1830(L)×495(H) 6-20T 1870(W)×1830(L)×500(H) +400/-300
HX-GTY6.5×6 1980(W)×1830(L)×495(H) 6-20T 2020(W)×1830(L)×500(H) +400/-300
HX-GTY7×6 2130(W)×1830(L)×495(H) 6-20T 2170(W)×1830(L)×500(H) +400/-300
HX-GTY6×8 1830(W)×2280(L)×495(H) 6-20T 1870(W)×2280(L)×500(H) +400/-300
HX-GTY6.5×8 1980(W)×2280(L)×495(H) 6-20T 2020(W)×2280(L)×500(H) +400/-300
HX-GTY7×8 2130(W)×2280(L)×495(H) 6-20T 2170(W)×2280(L)×500(H) +400/-300
HX-GTY6×10 1830(W)×2850(L)×495(H) 6-20T 1870(W)×2850(L)×500(H) +400/-300
HX-GTY6.5×10 1980(W)×2850(L)×495(H) 6-20T 2020(W)×2850(L)×500(H) +400/-300
Product Images
Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler 0 Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler 1 Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler 2
About Our Company
Guangdong Haoxiang Machinery Manufacturing Co., Ltd. is located in Xiaolan Town, Zhongshan City. We are a high-tech enterprise focusing on hydraulic logistics equipment, a manufacturer with a special equipment license, a registered capital of 30 million, an annual output value of over 100 million, a large production workshop, and a plant area of 21,500 square meters.
We take "creating safe and convenient lifting products for users" as our original intention, and mainly engage in hydraulic lifting platforms, etc., positioning "super safe and efficient lifts". The product design is novel and the operation is stable, and they are used in many fields such as logistics. With advanced equipment and fine management, We are a benchmark in the industry such as warehousing management.
We have served more than 40,000 companies and 45 installation teams, which provide 2-hour door-to-door service in the Pearl River Delta and 24-hour door-to-door service nationwide, so that you can use our products without any worries.
Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler 3 Fixed Scissor Lifting Platform: Large Custom Space-Saving High-Height Solution for Warehouse Cargo Transport + Edge-Mounted Dock Leveler 4
