Product Details:
|
Product Name: | Goods Lift | Color: | White |
---|---|---|---|
Lifting Height: | 3000mm | Load Capacity: | 1000kg |
Drive Type: | Hydraulic | Material: | Steel |
Table Size: | 1200*1300mm | Warranty: | 1 Year |
Highlight: | hydraulic warehouse cargo lift,1000kg freight elevator,industrial hydraulic lift platform |
Product name
|
Freight elevator cargo lift
|
Rated load
|
1000-3000kg
|
Lifting speed
|
6m/min
|
Warranty period of core components
|
1 year
|
Material
|
H Steel
|
Pump station
|
3kw/ 4kw 15.5kw/7.5kw
|
Oil cylinder
|
70/180/190/1100/120/140
|
A freight lift is built to facilitate the vertical transfer of cargo across different levels. It proves valuable in factories for material handling, warehouses for goods storage and movement, shopping complexes for shelf and product transport, and hotels for the distribution of food, linen, and operational items.
Specifications, sizes and colors can be customized according to customer requirements.
Model | Rated load (kg) | Lifting stroke (mm) | Lowering height (mm) | Table size (mm) | Lifting time | Motor power (kw) |
---|---|---|---|---|---|---|
DSL1-3 | 1000 | 3000 | 100 | 2000×1800 | 6m/min | 3 |
DSL1-12 | 1000 | 12000 | 100 | 2500×2000 | 6m/min | 3 |
DSL2-4 | 2000 | 4000 | 150 | 2000×1800 | 6m/min | 4 |
DSL2-10 | 2000 | 10000 | 200 | 3000×3500 | 6m/min | 4 |
DSL3-5 | 3000 | 5000 | 150 | 3000×1800 | 6m/min | 5.5 |
DSL3-8 | 3000 | 8000 | 150 | 2000×1700 | 6m/min | 5.5 |
DSL4-5 | 4000 | 5000 | 250 | 3000×4000 | 6m/min | 7.5 |
DSL4-10 | 4000 | 10000 | 150 | 5000×3000 | 6m/min | 7.5 |
DSL5-6 | 5000 | 6000 | 400 | 5800×3000 | 6m/min | 11 |
DSL10-15 | 10000 | 15000 | 400 | 7000×5000 | 6m/min | 18.5 |
DSL15-9 | 15000 | 9000 | 800 | 8000×4000 | 6m/min | 30 |
DSL15-10 | 15000 | 10000 | 800 | 9000×4500 | 6m/min | 30 |
Situated in Xiaolan Township, Zhongshan City, Guangdong Haoxiang Machinery Manufacturing Co., Ltd. operates as a certified high-technology manufacturing enterprise specializing in hydraulic logistics solutions. With 30 million RMB registered capital and annual production value exceeding 100 million RMB, our company maintains a 21,500-square-meter modern production facility.
Committed to developing ultra-safe, high-efficiency lifting systems, we prioritize creating innovative hydraulic lifting platforms that deliver reliable performance across logistics, warehousing, and industrial applications.
Equipped with advanced manufacturing technologies and rigorous quality control systems, we have established ourselves as an industry benchmark recognized for precision engineering and operational excellence. Our extensive service network includes 45 professional installation teams supporting over 40,000 client enterprises nationwide.
We guarantee rapid-response services with 2-hour on-site support available in the Pearl River Delta region and 24-hour emergency response coverage across China, ensuring complete peace of mind for all equipment users.
Contact Person: Ms. Sales
Tel: +86-13823983315
