3t 3stop CE Approved Cargo Lift Platform Freight Elevator Cage Lift in Warehouse

Large Image : 3t 3stop CE Approved Cargo Lift Platform Freight Elevator Cage Lift in Warehouse

Product Details:

Place of Origin:	GUANGDONG,CHINA
Brand Name:	HAOXIANG BRAND
Certification:	CE/ISO
Model Number:	DSL 3-8

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	USD2300- USD5000 / UNIT
Packaging Details:	Naked packaging
Delivery Time:	7-15 working days
Payment Terms:	T/T
Supply Ability:	1500 UNITS PER YEAR

Contact Now

3t 3stop CE Approved Cargo Lift Platform Freight Elevator Cage Lift in Warehouse

Description

Product Name:	Hydraulic Guide Rail Lift	Control Mode:	Hydraulic
Color:	Customers' Requirements	Floor Height:	1-7th Floor/Customizable
Rated Load:	Up To 30 Tons,Customizable	Application:	Loading And Unloading Goods Between Trucks And Warehouse
Material:	Steel	Type:	Cargo Lifts
Power Supply:	AC 380V/50Hz	Entrance:	Front/Through/90 Degree
Highlight:	3t CE approved cargo lift , warehouse freight elevator cage , industrial hydraulic platform lift

3t 3stop CE Approved Cargo Lift Platform Freight Elevator Cage Lift in Warehouse

Product Specifications

Attribute	Value
Product Name	Hydraulic Guide Rail Lift
Control Mode	Hydraulic
Color	Customers' Requirements
Floor Height	1-7th Floor/Customizable
Rated Load	Up to 30 tons, Customizable
Application	Loading and unloading goods between trucks and warehouse
Material	Steel
Type	Cargo Lifts
Power Supply	AC 380V/50Hz
Entrance	Front/Through/90 Degree

Product Overview

2t 3stop CE Approved Cargo Lift Platform Freight Elevator Cage Lift in Warehouse

Parameter	Specification
Product Name	Hydraulic Guide Rail Lift
Country of Origin	Made in China
Feature	Explosion-Proof, Insulating
Platform Size	1500X2000mm or Customized
Lift Mechanism	Lift Chain

What is the Hydraulic Guide Rail Lift?

Commercial cargo lifts are elevators that carry goods. Our commercial cargo lifts are widely used in commercial places, such as hotels, warehousing and logistics, car shops, and large supermarkets for cargo transportation between different floors.

Its biggest feature is that it can be customized. The voltage, table size, lifting height, load, import and export direction can be customized according to customer needs, and guardrail doors can also be installed. The biggest advantage of the freight cargo lifts are that it has very small requirements for the installation environment and is simple to install.

Key Benefits

Rugged Hydraulic Powertrain: A heavy-duty hydraulic mechanism delivers seamless, dependable vertical movement of massive loads with pinpoint accuracy.
Impressive Weight Handling: Engineered for extreme tonnage, the lift relocates oversized or dense freight with ease.
Indoor-Outdoor Flexibility: Weather-proof parts and a rugged frame allow installation inside or outside.
Comprehensive Safety Suite: Emergency-stop switches, protective gates, and overload sensors are standard.
Maximum Vertical Footprint: A space-savvy layout exploits every inch of height while keeping the overall footprint tight.

Technical Specifications

Specifications, sizes and colors can be customized according to customer requirements.

Model	Rated load (kg)	Lifting stroke (mm)	Lowering height (mm)	Table size (mm)	Lifting time	Motor power (kw)
DSL1-3	1000	3000	100	2000×1800	6m/min	3
DSL1-12	1000	12000	100	2500×2000	6m/min	3
DSL2-4	2000	4000	150	2000×1800	6m/min	4
DSL2-10	2000	10000	200	3000×3500	6m/min	4
DSL3-5	3000	5000	150	3000×1800	6m/min	5.5
DSL3-8	3000	8000	150	2000×1700	6m/min	5.5
DSL4-5	4000	5000	250	3000×4000	6m/min	7.5
DSL4-10	4000	10000	150	5000×3000	6m/min	7.5
DSL5-6	5000	6000	400	5800×3000	6m/min	11
DSL10-15	10000	15000	400	7000×5000	6m/min	18.5
DSL15-9	15000	9000	800	8000×4000	6m/min	30
DSL15-10	15000	10000	800	9000×4500	6m/min	30
